环保量油孔

更新:2015-8-16 13:36:03      点击:
  • 产品品牌   上海石化机械厂
  • 产品型号
  • 产品描述

    ...

产品介绍

一、环保型量油孔应用范围:
目前大部分量油孔采用方便简单的脚踏式,可以满足完成测量程序的要求,但是在某些特定介质工作状态下,确保环境不受影响和操作工人操作安全,同时化工物料均带有不同程度的有害气味,测量时不能排放到大气中,环保型量油孔就能起到这方面的作用。
The amount of oil hole at the top of the petroleum, chemical storage tanks, used to measure the elevation of the tank material, temperature, and sampling. Chemical materials with different levels of harmful odor, the measurement can not be discharged into the atmosphere. In order to complete the measurement procedures to ensure that the environment is not affected and the operation of the operational safety of workers, the amount of environmentally friendly hole will be able to play this role.
 我司生产的环保型量油孔采用碳钢或不锈钢钢板焊接而成,安装于石化储罐顶部,用以测量罐内物料的标高、温度以及取样等作用。二、环保型量油孔操作方法:
  环保型量油孔安装在储罐顶上,平时均能绝对密封,需要测量化工品时,先旋开、拔出测量口密封件,将窄口式测量组件放在上盖中间拧紧,再按下中间密封操作手柄,就能打开筒体密封件,此时将测量尺从上方窄口缝中伸入,即可测量液位的标高。操作完成后先拉回手柄,取出测量组件,再放入密封件拧紧。如对油品进行测量、取样时,拉下中间操作手柄,打开上盖即可。
三、环保型量油孔结构特点:
环保型量油孔(LYK-H型)具有产品结构紧凑,操作安全方便,采用双密封装置,具有防毒功能,既可适用于化工罐,又可适用于油品罐,适用面广等特点。


四、环保型量油孔外形连接尺寸:

规格DN

安装尺寸(mm













L

H

D

D1

K

n

L



150

400

650

265

200

225

8

18
